Electric Submersible Dewatering Pumps ( Ak-35350m-l-2P ) Manufacturer

Model No. : AK-35350m-L-2P

Motor Rating:
35HP (26.11KW)/3Ø/50Hz/415Volt, 2800 RPM
DOL Start squirrel cage continuous rated induction motor, insulation Class H (1800C).

Full Load Current:
46 Amps @ 415 Volt/3Ø/50Hz Ac Supply

Discharge Connection:
6”/8” Aluminum, Hose type.

Start/Stop: Max.15 per hour.

Power Cable:
15 meter, Water proof PVC insulated, flexible power cable of size 4 Core X 10 sq.mm.
*Use rated current when sizing control equipment.

Mechanical Seal :
Double seals of Inner lip seal & Outer Tungsten Carbide Vs Tungsten Carbide and are wholly
enclosed in oil chamber.

Materials:
Casted Parts : Aluminum Alloy LM4
Outer Casing : Stainless Steel 304
Motor Casing : Aluminum Alloy LM4
Motor Shaft : Stainless Steel 431
Impeller : Stainless Steel 410,
Hardened (HRC-55)
Fasteners : Stainless Steel 304
Oil Chamber : Aluminum Alloy LM4
Diffuser : Nitrile Rubber Coated
Strainer : Stainless Steel with circular holes of 12mm X 12mm.

Limitations:

Max. Submergence depth-10 Mtr.
Max. Liquid Temperature-400C.

*These pumps must be used with external motor protection in accordance with technical data.

Weight: 205 KG (Approx) without Cable
