Electric Submersible Dewatering Pumps ( ak-small series )

Dewatering Pumps



Electric Submersible Dewatering Pumps

INTRODUCTION :
KPR`S dewatering submersible pumps, known for job site dependability. Pumps are constructed of strong die cast aluminum and stainless steel body parts;

APPLICATIONS
• Designed for residential, commercial and industrial application where sewage, effluent discharge and storm water drainage are essential.

• Effectively drains sumps, basements and construction sites

• Rapidly dewaters swimming pools, spas, hot tubs tanks and other water storage structures.

• Ideal for water fountains, sprinkler systems, aquariums and irrigation.

• Quit & efficient way to transfer water from ground level to overhead tanks in house and bungalows


ITEM 1" AK-0.5 Series
Pumping Fluid Cleaning water, muddy water, sump water
40' C-
Pump Material Polycorbonate
Silicon Carbide
SKF Upper & Lower
Aluminum Alloy LM-4
Aluminum Alloy LM-4
Motor Dry type, induction motor, 2-poles
Class F
Single Phase/115V/60Hz
SS 410

3mtr. PVC insulated with 3pin plug
Discharge Connection 1" NPT Threading type





Model HP PH Voltage Total Head (Max) ft Capacity (Max) gal/min Rated Current Amp Starting Method Float Total Hight Wt.
AK-0.3-2P 0.3 Single 115V 24' 52 6 Capacitor Incl 297mm 8Kg
AK-0.5-2P 0.5 Single 115V 33' 59 7 Capacitor Incl 312mm 9Kg










Dewatering Pumps ( AK Small Series.pdf )
